Woven Stabilization Fabric - Intermediate Grade C - 15 x 300

$2,455.78


FREE SHIPPING

Intermediate Grade C Woven Stabilization Fabric the a great solution for applications where it is essential that water is able to flow through the fabric and into the subgrade soil below.

Grade C has a high flow through rate and is strong at low strain rates. Grade C woven fabric has been tested by Geosynthetic Accreditation Institute lab for ASTM 4595 & D4491 strength and permittivity tests.

Woven Fabric Class: Intermediate Grade C

Flow Rate: 40 gpm/ft²

Grab Tensile Strength @ 5% Strain: 1500 lbs/ft

Grab Tensile Strength Ultimate: 3600 lbs/ft

Made from high-tenacity polypropylene yarn fibers. This fabric is ideal for situations where verified ASTM tests are required, and/or high flow through rate is needed for drainage.

**See below for a full list of woven fabrics and roll sizing>

15' x 300' Roll Size

NOTE: This product is ineligible for return or order cancellation once the order has been shipped. If you would like to purchase an equivalent or similar fabric which is eligible to be returned with a standard restocking fee please give us a call at (800) 520-7731.

Product Specifics

  • Model: FAB-WSF-INTC15300
  • Series: Woven Stabilization Fabric Material
  • Size: 15' x 300'
  • Square Feet / Roll: 4,500

Woven Stabilization Fabric

  • High Strength / Excellent Permittivity
  • Monofilament Woven Material
  • Contractor Grade
  • UV Resistant
  • Non-Biodegradable
  • Will Not Rot or Mildew
  • Resistant to Rodent and Insect Damage

All of our geotextile fabrics are professional-grade and are designed for use in both residential & commercial applications. Our fabrics are designed for years of continuous use in the designated application.

Download Specification Sheet
Woven Stabilization Fabric Installation Guide

FABRIC INSTALLATION

  • Level and smooth out the subgrade. Remove sharp rocks and other objects that could puncture the fabric during the installation.
  • Unroll and place the woven fabric on the desired area and pull taut. Provide an overlap ranging from 18" - 24" depending on the strength of the subgrade. Secure the fabric with fabric staples, staggering the staples at an approximate rate of 1 staple per 3 feet.
  • Carefully back fill with graded crushed stone onto fabric. Properly installed woven paver base fabric can improve the long-term performance of your project 50-70%.

Fabric Shipping Time - Georgia Warehouse:

  • Expedited shipping only available on orders over $2,000
         Call: (800) 520-7731 for pricing and ship times

By default, Intermediate Grade & Heavy Duty fabric orders ship from the Georgia warehouse where a full stock of fabric types are maintained. Most orders ship same day (M-F) if order is placed before 11:00 AM EST. Transit times displayed in the map are listed in business days, are approximate and are specific to the these fabric lines.

The day that the order is shipped is not counted as a transit day. Most fabric rolls ship via LTL freight. For expedited shipping rates please call: (800) 520-7731

The transit times displayed on the map are for our free shipping option.

Fabric Shipping Time - Southern
California Warehouse:

Note: By default, orders ship from the Georgia warehouse with the standard transit times shown above. If you would like your order to ship from the Southern California warehouse (Mira Loma) you must first call to check stock in this warehouse. Orders can also be picked up at this warehouse location if preferred. Southern California warehouse orders must be placed over the phone.

Most California warehouse orders ship same day (M-F) if the order is placed before 11:00 AM EST. Transit times displayed in the map are listed in business days, are approximate and are specific to the Intermediate Grade D and above along with the Heavy Duty fabric lines. The day that the order is shipped is not counted as a transit day. Most fabric rolls ship via LTL freight. For expedited shipping rates please call: (800) 520-7731

The transit times displayed on the map are for our free shipping option.
